2026 Sun Tracker Fishin' Barge® 22 XP3 - TRB5816

2026 Sun Tracker Fishin' Barge® 22 XP3

The 2026 SUN TRACKER® FISHIN’ BARGE® 22 XP3's third pontoon, lifting strakes, and hydraulic steering let it operate like a fiberglass boat with the stability only a pontoon can offer.

Captains can control it all with the SUN TRACKER FLARE™ touch-screen gauge display. Set up the 10' bimini top, grab your rod out of the lockable rod box, and post up in one of the two fishing decks—each of which sports a 16-gal. aerated livewell—and two swiveling fishing chairs next to rod and tool holders. The dual lounges or aft bench with hidden storage are ready for relaxation. The lounges’ all-new open section in the backrest increases accessible storage and even has extra cupholders. 2026 also brings a wider, ergonomic boarding ladder.

The FISHIN' BARGE 22 XP3 is the most equipped fishing pontoon in the SUN TRACKER lineup. If you're looking for the best, you've found it.

Features may include

Comfort, Convenience & Peace of Mind

10+LIFE™ Limited Lifetime Warranty: 10-year bow-to-stern warranty + limited lifetime structural & deck warranty

NMMA® certified

10' (3.05 m) Black SUN TRACKER® QuickLift™ Bimini top w/LED courtesy lights, storage pockets & protective boot

NEW integrated LED docking lights

Integrated LED navigation & anchor lights

4 folding mooring cleats & starboard side tie-off mooring eye

Port wheelchair-accessible gate

Livewell System

Bow 16-gal. (60.57 L) aerated livewell w/shutoff valve, drink holder, rod holder & composite lid w/fish ruler

Aft 15-gal. (56.78 L) aerated livewell/baitwell w/shutoff valve, drink holder, rod holder & composite lid w/fish ruler

Console

NEW console design & color

Driver console w/integrated storage, drink holders, built-in footrest & ergonomically-positioned controls

SUN TRACKER FLARE™ touchscreen gauge display w/NEW integrated GPS & NEW stereo control

NEW 12-button switch panel location

Tilt hydraulic steering w/deluxe soft-touch steering wheel

Interior

Patented built-in STOW MORE™ seat-back storage system for all couches

4 removable & folding fishing chairs w/heavy-duty 2-3/8" (6 cm) diameter pedestals

Front fishing station w/2 pedestal seat base locations; rail-mounted rod & tool holders; & bow starboard storage compartment w/drink holder, rod holder & composite lid w/fish ruler

Performance

Three 26" (66.04 cm) diameter high-buoyancy multichambered & internally-braced pontoon logs

XP3 performance strakes & wave-deflecting nose cone for maximum performance

Full-length, 1-piece longitudinal M-bracket deck supports

Full-width, heavy-duty extruded Z-bar deck supports that are thru-bolted to longitudinal M-brackets

Heavy-duty aluminum U-channel reinforcement behind bow deck trim

Exterior

Color: Charcoal, NEW Heritage Red or NEW Starlite Black fencing

NEW graphics

Patent-pending TRACK FORMED® fence design w/high-sheen finish for long-lasting cosmetics

Elevated fence panels for deck drainage & ventilation

Electrical

500 GPH (1,893 LPH) Ultima automatic bilge pump

Battery disconnect switch

Easy-access marine-grade automotive-style fuse panel w/latching fuse block door

Protective abrasion-resistant wire wrap

Water-resis

General

Year: 2026

Manufacturer: Sun Tracker

Model: Fishin' Barge 22 XP3

Trim: Base

Type: Pontoon

Dimensions

Pontoon Log Diameter: 26 in (66.04 cm)

Length Overall: 24 ft 2 in (7.37 m)

Deck Length: 22 ft 1 in (6.73 m)

Pontoon Length: 22 ft 3 in (6.78 m)

Towing Length: 32 ft 4 in (9.86 m)

Storage Length: 32 ft 4 in (9.86 m)

Deck Width: 8 ft 6 in (2.59 m)

Package Width: 8 ft 6 in (2.59 m)

Package Height: 9 ft 2 in (2.79 m)

Interior Depth: 27.25 in (69.21 cm)

Capacities

Fuel Capacity: 52 gal (196.82 L)

Seating Capacity: 11 persons

Max Persons Weight: 1575 lb (714.41 kg)

Max Persons, Motor and Gear: 2350 lb (1065.94 kg)

Weights

Average Package Weight: 4875 lb (2211.26 kg)

Average Dry Weight: 2880 lb (1306.35 kg)

Engine

Max Recommended Power: 200 HP

Construction

Pontoon Material: 0.100 5052 marine alloy
